Threaded cup brushes, knotted DIA

Cup brush knotted TBG dia. 65 mm M14 stainless steel diamond wire dia. 0.50 mm grit 270

TBG 65/M14 INOX 0,50 DIA 270

Item number:: 43703023
EAN:: 4007220160121

Cup brush knotted TBG dia. 65 mm M14 stainless steel diamond wire dia. 0.50 mm grit 270 1

Cup brush knotted TBG dia. 65 mm M14 stainless steel diamond wire dia. 0.50 mm grit 270 2

Cup brush knotted TBG dia. 65 mm M14 stainless steel diamond wire dia. 0.50 mm grit 270 3

Cup brush knotted TBG dia. 65 mm M14 stainless steel diamond wire dia. 0.50 mm grit 270 Youtube

Technical data

Distributor Search

Technical information

Cup brush knotted TBG dia. 65 mm M14 stainless steel diamond wire dia. 0.50 mm grit 270

Dia. external: 65 mm
Dia. filament material: 0.5 mm
Dia. thread: M14x2
Filament material: Stainless steel wire (INOX) diamond (DIA)
Grit size: 270
Length, filament: 22 mm
Max. RPM: 12500 RPM
Mounting system: Thread
Number, knots: 18 pcs.
RPM, optimum: 1.500 - 3.700 RPM
Packaging unit: 1 piece

Description

The knots of the brush are knotted to 50% of the length.

The brush achieves a better surface quality on uneven surfaces than conventional knotted brushes.

Brushes with stainless steel wire (INOX) diamond (DIA) filament material are suitable for applications that place particular demands on the aggressiveness of the brush. They are primarily used on materials with high material strength.

Stainless steel wire (INOX) diamond (DIA) withstands temperatures up to 450 °C.

Advantages

Optimal ratio of aggressiveness and flexibility.

Recommendations for use

Please observe the recommended rotational speeds.
For optimum results, use on powerful angle grinders.

Ordering notes

Grit size DIA 270 = D 64

Materials that can be worked: Aluminium; Bronze; Cobalt-based alloys; Hard non-ferrous metal; High-temperature-resistant materials; Mill scale; Nickel-based alloys (e.g. Inconell and Hastelloy); Nickel or titanium-based superalloys; Other non-ferrous metals; Soft titanium alloys (tensile strength 500 N/mm²); Stainless steel (INOX); Titanium; Titanium alloys; Tungsten carbide; Wear-resistant coatings (powder metal alloys and hardfacing alloys)

Applications: Cleaning; Deburring; Descaling; Removing oxide layers

Drive types: Angle grinder
